1. Power Supply: AC 100-240V, 50/60Hz;
2. Light Source: Options for 200/300/400W or 500/600W RGBW (4-color) or RGBWAL (5-color) LED chips;
3. Power Consumption: 230/330/430W;
4. Light Source Lifespan: ≥50,000 hours;
5. Color Rendering Index (CRI) & R9: Ra ≥95, R9 >93;
6. Zoom Angle: 15-55° motorized zoom;
7. Color Temperature: Options for 3200K or 5600K (single or dual color temperature); color mixing range: 2700K-10000K;
8. Control Channel Modes: Single color temp (1 or 3 CH), Dual color temp (7 CH);
9. Control Signal: DMX512/RDM protocol;
10. Dimming Precision & Method: Options for 30,000 or 55,000 levels; 0-100% smooth linear dimming; 3 selectable dimming curves;
11. Dimming Refresh Rate: >16K (selectable 16K/24K/32K); high-frequency control system ensures flicker-free and jitter-free light output;
12. Drive Method: Constant current drive;
13. Control Panel Display: LCD screen;
14. Luminous efficacy: 110 lm/W;
15. Strobe rate: 1–30 flashes/second;
16. Optical lens: High-transmittance Fresnel lens ensuring uniform light output and high luminous efficiency;
17. Material and structure: Die-cast aluminum alloy housing with an aluminum alloy heat sink for efficient heat dissipation from the light source;
18. Cooling method: Forced-air cooling using a high-thermal-conductivity aluminum alloy heat sink and a waterproof, silent fan;
19. Protection rating: IP55;
20. Operating temperature range: -20°C to 35°C; features a built-in sensor for over-temperature protection;
21. Mounting method: Supports both suspended and base-mounted installation;
22. Fixture weight: 6.8 kg;
23. Fixture dimensions: 180 × 264 × 410 mm;
