This product adopts a high-conductivity aluminum profile mold to form an integrated structure with good heat dissipation effect. It is designed according to 4K/HD conference technical parameter standards. It is widely used in multi-functional conference halls, video and telephone conference rooms, auditoriums, multimedia conference rooms and recording studios, audio-visual classrooms, theater auditoriums and other places.

1. Input voltage: AC90-260V/50/60Hz
2. Power: lamp bead power 200W, whole lamp power 230W;
3. Light source: 3200/5600K single color, 3200K+5600K two-color imported LED high-brightness lamp beads selection
4. Number of lamp beads: 1024
5. Light source life: 50,000 hours
6. Light efficiency: (3200K standard light effect 105 Im/W / 5600 K standard light effect 110 Im/W)
7. Color temperature: 3200/5600K single color, double color can be adjusted between 3200-5600K
8. Color rendering index: Ra≥95
9. Red saturation index: ≥93
10. Control channel mode: 2, 6CH selection;
11. Control signal: DMX512/RDM protocol;
12. Dimming accuracy and method: 8bit/16bit/24bit selection, 0-100% smooth linear dimming, 3 dimming curve selection;
13. Dimming refresh frequency: above 16K, you can choose 16K/24K/32K; the high-frequency control technology system ensures that the light of the lamp is flicker-free and jitter-free;
14. Transmission mode and pitch angle: The left and right sides of the light box adopt gear transmission (double gear transmission structure), with electric uniform speed adjustment, and a flip angle of 0~90°; the double gear transmission structure is characterized by uniform force, no out-of-step, misalignment, and problems such as sliding teeth, skipping teeth, and gear jamming;
15. Limiting and positioning methods: Hall and magnet sensing limits and positioning are used. This structure is installed in the gear box, which can achieve higher sensitivity and accuracy in limiting and positioning;
16. Lamp structure and material: It adopts an aluminum profile multi-guide rail integrated structure. The light box and outer frame are made of stretched aluminum, which has high precision and good heat dissipation effect;
16. Working temperature: -10°~40°;
17. Cooling system: Using high thermal conductivity pure aluminum profiles for fanless heat dissipation;
18. Noise: 0 db
19. Installation method: embedded hoisting, ceiling;
20. Lamp body size: 600*600*150mm (length*width*height)
21. Opening size: 590*524*150mm (length*width*height)
22. Packing size: 650×650×160mm (single unit)
23. Net weight: 11.7kg Gross weight: 12.8kg
