100W Recessed Spotlight
Recessed Spotlight
Brand: Aceda (Renfeng Film & TV Lighting) Product Name: Recessed Spotlight Model: Aceda-QSP100 Input Voltage: AC 100–240V, 50/60Hz Total Power: 120W
Product Details
Light Source: 100W COB (Single-color or Bi-color)
LED Lifespan: 50,000 hours
Luminous Efficacy: 105 lm/W
Color Rendering Index (CRI): Ra ≥ 93; R9 (Saturated Red) > 90
Optics: Aluminum reflector + Fresnel lens
Beam Angle Adjustment: Adjustable via rail and sliding slot mechanism; range: 25°–90°
Strobe: 1–30 flashes/second (electronic)
Dimming Range: 0–100% stepless linear dimming
Dimming Precision: 30,000 levels
Dimming Refresh Rate: 16kHz
Cooling System: Aluminum heatsink + forced air cooling via silent fan
Driver Type: Constant current driver
Control Mode: DMX512 signal control + 2.4G wireless remote & mode selection
DMX Channels: Selectable 5 or 6 channels
Installation Cutout: Circular hole (diameter 200mm, depth 180mm)
Protection Rating: IP20
Operating Temperature: -25°C to +35°C
Material & Structure: Engineering plastic + aluminum profile; integrated molding of the circular housing, curved yoke, and angle adjustment rail; mounting plate utilizes a snap-fit/slot structure (housing mounting points screw-lock into the slots)
Net Weight: 1.35 kg
Gross Weight: 1.8 kg
Packaging Dimensions: 31cm x 29cm x 27cm
