1. Power Supply: AC 100-240V, 50/60Hz;
2. Light Source: Minimum 760 full-spectrum, high-CRI SMD LED beads (rated ≥0.2W each);
3. Power: LED bead power: 100W/140W; Rated power: 120W/160W;
4. Light Source Lifespan: ≥50,000 hours;
5. Color Rendering Index: Ra ≥95, CRI ≥95, TLCI ≥95;
6. Beam Angle: 120°;
7. Color Temperature: Options for 3200K or 5600K (single-color) or adjustable bi-color (3200K–5600K);
8. Control Channel Modes: Single-color: 1CH or 3CH; Bi-color: 2CH, 5CH, or 6CH;
9. Control Signal: DMX512/RDM protocol;
10. Dimming Precision & Method: Selectable 8-bit, 16-bit, or 32-bit modes; 0–100% smooth linear dimming; 3 selectable dimming curves;
11. Dimming Refresh Rate: >16kHz (selectable 16kHz/24kHz/32kHz); high-frequency control system ensures flicker-free and jitter-free light output;
12. Drive Method: Constant current drive;
13. Control Panel Display: Digital display with rotary knobs for dimming and color temperature adjustment; 14. Strobe: 1–30 flashes/second;
15. Optical system: 1) Uses an imported milky-white PC light guide plate; ensures uniform light distribution without revealing individual LED dots, offers high luminous efficacy, and provides anti-glare performance; 2) Features a secondary optical correction honeycomb grid to eliminate harsh glare;
16. Material and structure: Utilizes a patented integrated structure combining aluminum alloy profiles with a high-thermal-conductivity aluminum alloy substrate, ensuring rapid heat dissipation from the LEDs;
17. Heat dissipation: Fanless, integrated aluminum alloy heat dissipation system relying on natural air convection;
18. Noise: Silent operation;
19. Protection rating: IP20;
20. Operating temperature: -20°C to 35°C; includes a built-in sensor for over-temperature protection;
21. Mounting method: Choice of three mounting options—manual suspension, pole-operated suspension, or motorized suspension;
22. Fixture weight: 4.05 kg / 5.15 kg;
23. Fixture dimensions: 566 × 284 × 90 mm / 530 × 306 × 90 mm;
24. Impact protection design: Features molded plastic corner protectors and suspension arm covers to prevent damage from collisions; available in three colors—Diamond Black, Sky Blue, and Dawn Orange—exuding a sense of dignity, luxury, and prestige;
